Sale!

Free Shipping 100PCS/Lot FTTH ESC250D SC APC and SC UPC Single-Mode Fiber Optic Quick Connector FTTH SM Optic Fast Connector

0
Add to compare
SKU: 32996802987 Category:

$114.66$151.20

SC APCSC UPC
Clear

1. FTTH project usable

2. Field installable

3. Insert loss No more than 0.5dB

4. Metal V-shape cavity work well in high and low temperature

5. Installation less than 1 minutes

6. Reliable and superior optical performance

7. Cable Tensile test complies with Telcordia GR-326-COR

Optical Characteristics

ITEM

Technical Parameters

Applicable for

Drop cable / Indoor cable

0.9mm Tight Buffer Fiber, 2.0mm, 3.0mm Drop Cable

Optical fiber diameter

SM(9/125), MM(50/125, 62.5/125)

125μm ( 657A & 657B )

Tight buffer diameter

250μm

Fiber mode

Single mode

Operation time

About 100s(no fiber cut)

Insert loss

≤ 0.3dB(1310nm & 1550nm)

Return loss

> 50db(PC), > 55db(UPC), > 65db(APC)

Fastening strength of naked fiber

>5 N

Fastening strength of naked fiber holder

>10 N

Tensile strength

>50 N

Using temperature

-40~+75°C

On-line tensile strength (20 N)

IL ≤ 0.5dB RL ≤ 5dB

Mechanical durability (500 times)

IL ≤ 0.5dB RL ≤ 5dB

Drop-off test (drop-off height 4m,once per direction, totally 3 times)

IL ≤ 0.3

Specification: Free Shipping 100PCS/Lot FTTH ESC250D SC APC and SC UPC Single-Mode Fiber Optic Quick Connector FTTH SM Optic Fast Connector

Brand Name

Joinwit

Connector Type

SC/APC

Fiber Type

Single Mode

Item Length

1m

Size

20cmx20cmx20cm

Compatible

TP-link

Model Number

SC/APC Fast Connector

Storage Temperature

25 ~+85

Repeatability

<=0.5dB

Mode

single mode, multimode

Diameter

0.9mm, 2.0mm, 3.0mm, Others

Durability

500 Times
